Bubble Bag Making Machine with Double Folder System
Approx. Price: 550000 onwards
Sealing Length
:1000 mm., 1500 mm
Machine Power
:3.0kw, 3 Phase./ 1 single phase
:35-40 Stroke/min.(For 150 mm , 1mm foam)
:PLC Delta Taiwan Make
:Strong wooden Packing
Payment Mode Term
:T/T(Bank Transfer)
Air requirement
:2 – 3 CFM at 6 Bar Pressure
Port of Dispatch
Delivery Time
:6-7 weeks
  • Authentic Designers presents you with Bubble Bag Making Machine with a Double Folder System that helps in reducing the workload and workforce and minimizes the human interaction while the machine is running, and provide a utility that ultimately decreases the use of the work power in the business.




    • Sealing Lemgth: 1000 mm. & 1500 mm
    • Two pouches of 500mm each can be made from the machine.
    • Material: Air Bubble Sheet Bag Making.
    • Power: 3.0kw, 3 Phase./ 1 single phase
    • Speed: 35-40 Stroke/min.(For 150 mm , 1mm foam)
    • Automatic Length adjustment through digital Control Panel
    • Servo controlled pulling system (Servo Make Delta Taiwan) Heavy Duty Servo
    • Special heavy-duty, continuous rating helical gearbox
    • Double unwind and turn bar / Folder assy. (Stainless steel triangular Folder)
    • Heavy-duty, dynamically balanced Aluminium roller to support the sheet during folding operation and smooth running of the sheet – 10 nos.
    • Adjustable pinch roller to guide the sheet after folding
    • Heavy Duty Linear motion bearing slide with heavy-duty pneumatic cylinders for perfect alignment of sealing bar ensuring trouble-free operation.
    • Separate Pneumatic valve for each cylinder.
    • Highly accurate and easy to adjust M 18 Proximity sensor for sensing the sealing jaw position.
    • SS front Tray and SS top on Backside
    • Alarm system for bag counting
    • Alarm for starting and end of machine run cycle
    • Any error happening in the motor or sensors will be displayed in the digital display thus making it very easy to detect the problem
    • Powder-coated, proper ventilated control panel
    • Complete P.L.C. Controlled System. .(PLC Delta Taiwan Make)
    • Digital Display Meter for Parameter Setting with Bag Cutting Counter.
    • Heavy Duty Pneumatic Cylinders Used.
    • Pneumatic Operations Used for Efficient Bag Sealing.
    • Very simple operation and low maintenance.
    • State of the art technology used.
    • Compressed Air Required 2 – 3 CFM at 6 Bar Pressure.
